Lead Acid Battery

Pure Lead Battery for UPS/Telecom(Plateaus-12150)

Brief introduction Parameter Feature Transport Package

Nominal Voltage: 12V

Nominal Capacity: 150AH

Approximate Weight: 42Kgs (92.57Ibs)

Dimensions: 483(19.02)*170(6.69)*240(9.45)*240(9.45) mm/in

Packing Data for 20GP FCL
Qty of battery	Cases/20GP	Total G.W.	Total Volume
570	19	24700	20.54
Battery will be put into carton box, then packed into plywood case. (1pc/Carton, 30pcs/Case)

INQUIRY

SolarWind System
Household ESS
Lighting/CCTV System
IndustricalCommercial ESS

Nominal Voltage	12V
Nominal Capacity	10Hr Rate to 10.8V @25℃(77℉) 150Ah
Cycle Use Charging Voltage	14.4V @25℃(77℉)
Terminal	M8-Φ18
Operating Temperature Range	-50℃ to 65℃(-58℉~149℉)
Advice operating temperature	15℃~25℃(59℉~77℉)
Self Discharge @ 25˚C(77˚F)	HUAFU Plateaus series battery self-discharge <3%/month@25℃(77℉),can be stored up to 6 months at 25℃(77℉) and then a freshening charge is required. If the storage temperature higher than 25℃(77℉), a freshening recharge will be required sooner.
Case and cover	A.B.S. (UL94-V0 Optional)
Design Life time	8 Years
