Lead Acid Battery

Pure Lead Battery for UPS/Telecom(Plateaus-1270)

Brief introduction Parameter Feature Transport Package

Nominal Voltage: 12V

Nominal Capacity: 70AH

Approximate Weight: 20.2Kgs (44.52Ibs)

Dimensions: 165(6.50)*126(4.96)*175(6.89)*181(7.13) mm/in

Packing Data for 20GP FCL
Qty of battery	Cases/20GP	Total G.W.	Total Volume
1140	19	24871	21.95
Battery will be put into carton box, then packed into plywood case. (1pc/Carton, 60pcs/Case)

INQUIRY

SolarWind System
Household ESS
Lighting/CCTV System
IndustricalCommercial ESS

Nominal Voltage	12V
Nominal Capacity	10Hr Rate to 10.8V @25℃(77℉) 70Ah
Cycle Use Charging Voltage	14.4V @25℃(77℉)
Terminal	M8-Φ16
Operating Temperature Range	-50℃ to 65℃(-58℉~149℉)
Advice operating temperature	15℃~25℃(59℉~77℉)
Self Discharge @ 25˚C(77˚F)	HUAFU Plateaus series battery self-discharge <3%/month@25℃(77℉),can be stored up to 6 months at 25℃(77℉) and then a freshening charge is required. If the storage temperature higher than 25℃(77℉), a freshening recharge will be required sooner.
Case and cover	A.B.S. (UL94-V0 Optional)
Design Life time	8 Years

RELATED PRODUCTS

Plateaus-1240

Design for area over 1500m above sea level. CNJ Seires plateau gel battery 12V40Ah owes the good performance of low temperature low pressure.

Capacity AH:40 Voltage: 12V
VIEW
Plateaus-1224

Design for area over 1500m above sea level. CNJ Seires plateau gel battery 12V24Ah owes the good performance of low temperature low pressure.

Capacity AH:24 Voltage: 12V
VIEW
Plateau-500

Design for area over 1500m above sea level. CNJ Seires plateau gel battery 2V500Ah owes the good performance of low temperature low pressure.

Capacity AH:500 Voltage: 2V
VIEW
Plateaus-12200

Design for area over 1500m above sea level. CNJ Seires plateau gel battery 12V200Ah owes the good performance of low temperature low pressure.

Capacity AH:200 Voltage: 12V
VIEW

BRAND PROMISE

QUALITY
Use the best raw materials, bring in the latest tech-nology and stringent quality control, continuously improve the production process, strictly implement ISO14001 quality management system.
EXPERIENCE
Foucs on the only career of battery manufacturing for 100 years. Service for thousands of enterprises and projects. Rich experience helps us and customer part from competition.
SERVICE
Quick Delivery (7-15days), accpect customized battery(OEM). Timely and fast aftersales and technical support. Help to choose the right and best battery solution.

If you need help to select the right battery for your particular application, please feel free to contact us, we have a highly trained and qualified team of experts who will be pleasure to do that.
