Lead Acid Battery

Pure Lead Battery for UPS/Telecom(Plateau-2000)

Brief introduction Parameter Feature Transport Package

Nominal Voltage: 2V

Nominal Capacity: 2000AH

Approximate Weight: 114.0Kgs (251.26Ibs)

Dimensions: 433(17.05)*342(13.46)*341(13.43)*351(13.82) mm/in

Packing Data for 20GP FCL
Qty of battery	Cases/20GP	Total G.W.	Total Volume
210	35	25025	19.42
Battery will be packed into plywood case. (6pcs/Case)

INQUIRY

SolarWind System
Household ESS
Lighting/CCTV System
IndustricalCommercial ESS

Nominal Voltage	2V
Nominal Capacity	10Hr Rate to 1.8V @25℃(77℉) 2000Ah
Cycle Use Charging Voltage	2.4V @25℃(77℉)
Terminal	M8-Φ20
Operating Temperature Range	-50℃ to 65℃(-58℉~149℉)
Advice operating temperature	15℃~25℃(59℉~77℉)
Self Discharge @ 25˚C(77˚F)	HUAFU Plateaus series battery self-discharge <3%/month@25℃(77℉),can be stored up to 6 months at 25℃(77℉) and then a freshening charge is required. If the storage temperature higher than 25℃(77℉), a freshening recharge will be required sooner.
Case and cover	A.B.S. (UL94-V0 Optional)
Design Life time	15 Years
