Lead Acid Battery

IP67/IP68 Solar Street Light Battery(12V 30Ah [IP67])

Brief introduction Parameter Feature Transport Package

Nominal Voltage: 12V

Nominal Capacity: 30AH

Approximate Weight: 10.3Kgs (22.70Ibs)

Dimensions: 196(7.72)*165(6.50)*174(6.85)*181(7.13) mm/in

Packing Data for 20GP FCL
Qty of battery	Cases/20GP	Total G.W.	Total Volume
1900	19	24605	27.02
Battery will be put into carton box, then packed into plywood case. (2pcs/Carton, 192pcs/Case)

INQUIRY

SolarWind System
Household ESS
Lighting/CCTV System
IndustricalCommercial ESS

Nominal Voltage	12V
Nominal Capacity	10Hr Rate to 10.8V @25℃(77℉) 30Ah
Cycle Use Charging Voltage	14.4V @25℃(77℉)
Terminal	M6-Φ16
Operating Temperature Range	-35℃ to 60℃(-31℉~140℉)
Advice operating temperature	15℃~25℃(59℉~77℉)
Self Discharge @ 25˚C(77˚F)	HUAFU CNJ series deep cycle gel battery self-discharge <3%/month@25℃(77℉),can be stored up to 6 months at 25℃(77℉) and then a freshening charge is required. If the storage temperature higher than 25℃(77℉), a freshening recharge will be required sooner.
Case and cover	A.B.S. (UL94-V0 Optional)
Design Life time	12 Years
